CherryMAX CR3243-4-04 Blind Rivet, 1/8 in Dia, 1.504 in L, 1/4 in Hole Dia, 0.188 to 1/4 in, 345 lb

CherryMAX is a locked spindle blind rivet with a visibly inspectable mechanical locking device and its own installation washer, which eliminates the problems resulting from worn tool anvils. It is called a bulbed fastener due to its large blind side bearing surface, developed during the installation process. CherryMAX rivets are used in thin sheet applications and for use in materials that may be damaged by other types of blind rivets. The CherryMAX rivet is the most reliable, high strength structural fastener with visual inspectability in the world today. It features the safe-lock locking collar for more reliable joint integrity and meets the requirements of PS-CMR-3000. CherryMAX tooling provides the simplest, most trouble-free installation tooling system. CherryMAX fasteners are currently available in 1/8 through 1/4 in diameters in both nominal and 1/64 in oversize diameters. The tools use a single pulling head to install many diameters, head configurations and material combinations. FEATURES • A fully serrated stem with break notch, shear-ring and integral grip adjustment cone • A driving anvil to insure a visible mechanical lock with each fastener installation • A separate, visible and inspectable locking collar that mechanically locks the stem to the rivet sleeve • A rivet sleeve with recess in the head to receive the locking collar SPECIFICATIONS • Series: CR3243 • Diameter: 1/8 in • Length: 1.504 in • Head Diameter: 1/4 in • Head Height: 0.054 in • Head Type: Universal • Hole Size: 0.143 to 0.146 in • Shank Diameter: 0.125 in • Shank Style: Drive Pin • Tensile Strength: 345 lb • Shear Strength: 814 lb • Grip Range: 0.188 to 1/4 in • Sleeve Material: Aluminum • Stem Material: Stainless Steel Alloy
